SmartView Display 2100-SVD
Only available in
COMPLIANT WITH
Overview
The 2100-SVD SmartView Display integrates with the SmartView Controller. It displays 5/16″ text from a call center on a 5″ screen.
SmartView Two-Way Elevator Visual Communication System
Dimensions:
- Overall: 2.98″ H x 5.35″ W x 0.63″ D
- Panel Cut Out: 2.67” H x 4.37” W ” D
Part Numbers:
- 2100-SVD: 0.0625″ window
- 2100-SVDA: 0.125″ window
- 2100-SVDB: 0.109″ window
- 2100-SVDC: 0.078″ window
- 2100-SVDE: 0.118″ window
Code Compliance:
Certified to CSA Standard B44.1, conforms to ASME Standard 17.5
Power Requirements: 5V/1A power supply with 5.5mm barrel connector, or powered by the SmartView Controller
Wiring Requirements: Includes 20′ power cable and 20’ HDMI cable to connect to the SmartView Controller
Additional Features:
- Includes clear protective window
- 5″ screen size
- 3/16″ default text size
- 800 x 480 pixels
- 75° viewing angle
Specifications:
- Environmental: -4°F to 158°F (-20° C to 70° C)
- Mounting: Mounting Plate included
Warranty: 2 years
